Mitutoyo Absolute Digimatic Digital Vernier Caliper 0-200mm SPC Data Output
ABSOLUTE Digimatic Caliper SERIES 500 — with exclusive ABSOLUTE Encoder Technology
An ABSOLUTE electromagnetic induction linear encoder system is incorporated.
New ergonomic design with finger rest.
The ZERO/ABS button allows the display to be Zero-Set at any slider position along the scale for comparison measurements. Scale overspeed-error has been eliminated for maximum reliability.
Large and clear LCD readout.
Smooth slider movement makes for comfortable operation.
Extended battery life of Approx. 5 years due to low current integrated circuit.
Allows step measurement.
Allows integration into statistical process control and measurement systems for models with measurement data output connector.
Technical Data:
Range: 0 - 200 mm
Depth bar: Flat
Thumb roller: Yes
Data output: Yes
Max. Permissible Error E MPE: ±0.02 mm
Max. Permissible Error S MPE: ±0.04 mm
Digital step: 0.01 mm
Max. response speed: Unlimited
Display: LCD, character height 9 mm
Delivered: In a case, including 1 SR-44 battery
ORIGIN (ABS-Zero): Yes
ON/OFF: Yes
ABS / INC (INC ZERO): Yes
Low voltage alarm: Yes
Battery life: Approx. 5 years under normal use
Mass: 198 g
Model #: 500-152-30 (metric only)
MADE IN JAPAN
——————————————————————————————————————
Mitutoyo Digimatic USB Input Tool Direct with SPC Data Output Button
Measurement data can be entered into Excel, Notepad, etc. simply by connecting to a PC.
The combination of simple operability (HID) and optional software for Excel input enables one step higher work efficiency.
Technical Data:
Cable length: 2 m
Model: C Straight Type with output button
Communication speed (Mbps): 12
Output specification: USB (1 channel)
Power supply: USB bus power
Output: USB HID and VCP (with optional software USB-ITPAK)
Remarks: USB Input Tool Direct Cable Straight With Data Switch (2.0m); e.g. for Standard Absolute Caliper
OS compatibility: Windows® 2000 Professional (≥SP4), Windows® XP Professional (≥SP2), Windows® XP Home Edition (≥SP2), Windows Vista®/7 (32bit,64bit), Windows® 8, 8 .1, 10 (32bit,64bit)
Max connectable devices: Microsoft® Windows® 2000, XP: 100 cables, Windows® Vista®, 7, 8, 8. 1, 10: 20 cables
Mass: 59 g
Model Compatibility:
Digimatic caliper: 500-150-30/500-151-30, etc. 500-500-10/500-501-10, etc. 500-443 etc.
Digimatic special application caliper: 573-118-10/573-119-10. etc. 573-116-10/573-117-10, etc. 573-191-30/573-291-30 573-181-30/573-182-30, etc.
Digimatic depth gage: 571-201-30/571-202-30, etc.
Digimatic micrometer head: 164-163/164-164
Digimatic scale unit: 572-203-10/572-213-10 572-300-10/572-301-10, etc.
*Since this device is compatible with Windows standard driver software, dedicated driver software is not required.*
Model #: 06AFM380C
MADE IN JAPAN
